8-215079-6
CONN RCPT 16POS 0.1 TIN PCB
part Number：
8-215079-6
Alternative Model：
manufacturer：
TE Connectivity AMP Connectors
category：
Connectors, Interconnects >
Rectangular Connectors >
Headers, Receptacles, Female Sockets >
describe：
CONN RCPT 16POS 0.1 TIN PCB
RoHS：
YES
8-215079-6 specifications
Mounting Type：
Through Hole
Part Status：
Active
Features：
-
Number of Rows：
2
Pitch - Mating：
0.100" (2.54mm)
Ingress Protection：
-
Material Flammability Rating：
UL94 V-0
Contact Material：
Phosphor Bronze
Number of Positions：
16
Number of Positions Loaded：
All
Connector Type：
Receptacle
Fastening Type：
Push-Pull
Insulation Material：
Polybutylene Terephthalate (PBT), Polyester, Glass Filled
Operating Temperature：
-40°C ~ 105°C
Mated Stacking Heights：
-
Row Spacing - Mating：
0.100" (2.54mm)
Contact Finish Thickness - Post：
-
Contact Type：
Forked
Contact Finish - Mating：
Tin
Contact Finish - Post：
Tin
Current Rating (Amps)：
-
Style：
Board to Board or Cable
Contact Finish Thickness - Mating：
-
Insulation Color：
Red
Termination：
Kinked Pin, Solder
Insulation Height：
0.157" (4.00mm)
Contact Shape：
-
Applications：
Automotive, General Purpose
Contact Length - Post：
0.122" (3.10mm)
Voltage Rating：
100VDC
