75160-311-36
CONN HEADER VERT 36POS 2.54MM
part Number：
75160-311-36
Alternative Model：
manufacturer：
Amphenol ICC (FCI)
category：
Connectors, Interconnects >
Rectangular Connectors >
Headers, Male Pins >
describe：
CONN HEADER VERT 36POS 2.54MM
RoHS：
YES
75160-311-36 specifications
Part Status：
Obsolete
Mounting Type：
Through Hole
Features：
-
Pitch - Mating：
0.100" (2.54mm)
Operating Temperature：
-
Ingress Protection：
-
Material Flammability Rating：
UL94 V-0
Contact Material：
Phosphor Bronze
Applications：
-
Number of Positions Loaded：
All
Termination：
Solder
Voltage Rating：
-
Number of Rows：
1
Contact Type：
Male Pin
Number of Positions：
36
Row Spacing - Mating：
-
Style：
Board to Board
Shrouding：
Unshrouded
Fastening Type：
Push-Pull
Insulation Height：
0.100" (2.54mm)
Contact Shape：
Square
Insulation Color：
Black
Mated Stacking Heights：
-
Connector Type：
Header
Insulation Material：
Thermoplastic
Contact Finish - Mating：
Tin-Lead
Contact Finish - Post：
-
Contact Finish Thickness - Post：
-
Current Rating (Amps)：
-
Overall Contact Length：
0.560" (14.22mm)
Contact Finish Thickness - Mating：
150.0µin (3.81µm)
Contact Length - Mating：
0.225" (5.72mm)
Contact Length - Post：
0.235" (5.97mm)
